Wood Pellet Production Line
The complete biomass wood pellet production line Including chipping section, grinding section, drying section, storing materials section, pelletizing section, cooling section, packing section and computer control terminal system. Depending on the raw materials used, the equipment used will vary.
|
Key attributes |
|||
| Type | Pulverizer | Voltage | 220V/380v |
|
Core Components
|
wood processing,Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine, Pressure vessel, Other | production capacities | 0.6T/H-7T/H |
| Applicable Industries | Manufacturing Plant, Farms, Home Use, Energy & Mining, pellet plant | Material | wood type, grasses, corn stalks, mixed woods,Other |
| PRODUCT MODEL MOLD | |||||
| MODEL | YIELD(T) | POWER(KW) | MOLDAPERTURESIZE(MM) | PACKAGE SIZE (MM) |
WEIGHT(T) |
| GZLH-560 | 1-1.5T | 9OKW | 4-12MM | 2620*1640*1770 | 5.2 |
| GZLH-560A | 1.5-2T | 132KW | 4-12MM | 2680*1560*1770 | 5.6 |
| GZLH-700 | 2-2.5T | 160KW | 4-12MM | 2560*1380*2020 | 7.2 |
| GZLH-860A | 3-4T | 250KW | 4-12MM | 3150*1550*2240 | 9.5 |
Raw Material
Wood
Bambo
Corn Stalks
Straw
Shell
PRODUCT STRUCTURE
